The 8-Port Gigabit PoE Switch accelerates productivity to Gigabit speeds, with PoE+, QoS and plug-and-play setup for ease of use.

Upgrade the data paths of your local wired network to information superhighways with 8-port desktop Gigabit PoE switches.

• Wired connection speed up to 1,000 Mbps
• 8 Gigabit Ethernet autosensing ports
• Power over Ethernet (PoE) support
• Easy plug & play connection
• QoS
• Meets EEE (Energy Efficient Ethernet) 802.3az standard

  Switch Type

  • Unmanaged



  Switch Ports

  • 8



  PoE+ Budget

  • Up to 110W



  PoE Support

  • Yes



  Power Consumption

  • 3.83 W / 7.0 W



  LEDs

  • Link, speed, activity, and PoE indicators



  Dimensions (LxWxH)

  • 210 x 104 x 25 mm (8.3 x 4.1 x 1.0 in.)



  Weight

  • 0.50 kg (1.10 lbs)



  Minimum System Requirements

  • Connected devices need Ethernet connectivity and Ethernet cables



  Operating Humidity

  • 10–90% (non-condensing)



  Operating Temperature

  • 0–50°C (32–122°F)



  Ports

  • 8-port switch with 4 PoE+ ports (first 1–4 ports) and dedicated PoE power budget of 50 W



  Mounting

  • Wall



  Quality Of Service

  • 802.1p and DSCP



  Storage Temperature

  • -40–70°C (-40–158°F)



  Warranty and Support

  • 5 Year Warranty



  MAC Address Table Size

  • 8,000 entries



  Performance

  • 0.01488 Mpps for 10M port
  • 0.1488 Mpps for 100M port
  • 1.488 Mpps for 1000M port
  • Full line rate and forwarding rate of 64B frame at:



  Power

  • 54 VDC, 1.2 A



  Regulatory Compliance

  • FCC Class A, CE



  Maximum Power Consumption

  • 1.71 W / 5.08 W



  Fans

  • None



  Power Consumption

  • 3.83 W / 7.0 W



  Storage Humidity

  • 10–90% (non-condensing)



  Power Saving

  • Cable connected detection, sleep mode



  Network Standards

  • IEEE 802.3
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.3at (PoE+)
  • IEEE 802.3az
  • IEEE 802.3u
  • IEEE 802.3x



  Bandwidth

  • 16 Gbps (non-blocking)



  2 Monitors

  • External
    • Linksys LGS108P 8-Port Gigabit Ethernet PoE Switch
    • Power Adapter
    • Quick Start Guide
    Features
