Description
Capacity: 1000VA / 1000W
Topology: Online double-conversion
Waveform: Sine wave
Outlets: 4
Features:
• 1.0 output power factor
• Zero transfer time from Line to Battery
• Adjustable charging current up to 12A
• High power factor charger with minimal ripple current
• 50/60Hz Frequency Converter Mode
• Emergency Power Off (EPO)
• ECO and Advanced ECO Modes
• Expandable runtime
• Optional external MBS PDU
| OVERVIEW | |
| Model | ULT-P1K |
| Capacity | 1000VA / 1000W |
| Topology | Online double-conversion |
| INPUT | |
| Voltage | 200 / 208 / 220 / 230 / 240 VAC |
| Voltage Range | 110 – 300Vac |
| Frequency | 40 – 70Hz |
| OUTPUT | |
| Output Voltage | 200 / 208 / 220 / 230 / 240 VAC |
| Frequency Range (on Battery) | 50 / 60 Hz +/- 0.1Hz |
| Current Crest Ratio | 3:1 (max) |
| Harmonic Distortion | <2% THD (linear load) |
| Wave Form (on Battery) | Sine wave |
| TRANSFER TIME | |
| Line to Battery | 0ms |
| Inverter to Bypass | 4ms (typical) |
| EFFICIENCY | |
| AC Mode | 89% |
| Battery Mode | 88% |
| ECO Mode | 97% |
| BATTERY | |
| Chemistry | Sealed lead-acid |
| Quantity & Size | 2 x 12V / 9Ah |
| Charging Voltage | 27.4 Vdc +/- 1% |
| Charging Current | 8A (Max.) |
| Recharge Time | 3 hours recover to 95% capacity
for 2A charging current |
| PROTECTION | |
| Emergency Power Off (EPO) | Yes |
| Overload Protection | Yes |
| Overcharge Protection | Yes |
| Surge Suppression | Yes |
| EMI / RFI Filter | Yes, full time |
| ADDITIONAL FEATURES | |
| Programmable Outlets | Yes |
| ECO Mode | Yes |
| Advanced ECO Mode | Yes |
| Frequency Converter Mode | Yes |
| COMMUNICATION | |
| USB Port | Yes, for power management software to control and monitor the UPS conditions |
| RS232 Port | Yes, for power management software to control and monitor the UPS conditions |
| Software | Compatible with Windows 10/8/7/ Server 2012 R2 / 2008 R2 / Linux 32-Bit / 64-Bit / mac 10.6 to 10.11 |
| Intelligent Slot | Yes |
| STATUS INDICATORS | |
| LCD Screen | Yes, for Input/Output Voltages, Battery Level, Fault, and more |
| Audible Alert | Yes |
| WARRANTY | |
| Warranty | 2-Year: Equipment and $25,000 Connected Equipment Warranties. 2-Year: Battery Warranty. See Terms of Use and Warranty pages for additional information. |
| PHYSICAL | |
| Color | Black |
| Form Factor | Tower |
| Product Dimensions (DWH) | 397 x 145 x 220 / 15.6 x 5.7 x 8.7 |
| Product Weight | 11.7 Kg / 25.8 lb (w/ batteries) |
| Product specifications are subject to change without further notice. Maruson assumes no responsibility, and disclaims all liability, for any damages that may result from the use of this information or for any errors or omissions. Battery backup time varies with equipment, configuration, battery age, temperature, etc. |
